Actuator Pulley Plate NEMA 17 Motor

This complete Solid Wheel Kit allows for easy assembly of V-Slot aluminum extrusions. The wheels are perfectly dimensioned to slide along the extrusions, providing low-friction, high-wear resistance, load distribution, and resistance to deflection. These wheels are the perfect choice for you to achieve smooth motion having light and medium loads in your system. They also are individually milled for consistent high precision and tolerance.

OpenRail is a versatile linear rail system that can be used with any V-Slot linear rail. It's perfect for use with our selection of OpenRail Gantry Plates and Delrin Dual V Wheels.

These V-Slot Modular Actuator End Mounts create belt-driven linear actuators when used with V-Slot Aluminium Extrusion. By mounting both a Nema 17 Stepper Motor and a Smooth Idler Pulley, you can create a linear actuator for your specific project needs.

The Smooth Idler Pulley Kit makes it easy to assemble an idler-free wheel that can be used with a timing belt up to 9mm wide. You can mount it in different ways depending on your design, including plate-mounted or direct tee slot-mounted using a tee nut and a spacer.

Check out our awesome, high-quality, custom-made aluminum spacers! They make great, sturdy standoffs/spacings for your projects. This Metric version of the spacer is 10mm OD and 5mm ID, so you know it'll be a stable platform. The spacer has M5 ID to give a thicker wall to keep the screw snug and centered.

This Anti-Backlash Nut prevents movement in the wrong direction, ensuring precise linear displacement. It features a mounting flange with four un-tapped holes for M3 screws, and it's intended to be used with Tr8x8(P2) leadscrews. These leadscrews are 8 mm-diameter rods with four independent trapezoidal threads spaced 2 mm apart. One full revolution of the rod results in an 8.0 mm linear displacement of the traveling nut.

The XYZ-Double Rail Gantry system is equipped with two linear actuators on the X-axis, a single linear actuator on the Y-axis, and one actuator on the Z-axis for movement. The length of the actuators is 1000mm, 500mm, and 250mm. Don't miss out on this great deal! Save 20% OFF on Kits.
