This Bundle is the perfect way to get all the parts you need for a V-Slot Mini V Wheel Gantry. The Mini V Gantry Plate can be used to mount the gantry on the 20mm side of any size V-Slot (2020, 2040, 2060, and 2080). The bundle is smaller than the other V-Slot Gantry Bundles, allowing for a more compact gantry to run on a 20mm V-Slot. The Mini V Wheels are perfect for this application.
Looking for a reliable and powerful blower fan? Check out our 12V DC Blower Turbine 50mm fan! It's perfect for cooling electronics, hotends, 3D prints and laser modules.
The Pivot Joint Connector lets you create multiple V-Slot and 2020 Series aluminum profile configurations. The breakaway tabs make it more flexible, so you can find the perfect setup for your project.
This Anti-Backlash Nut prevents movement in the wrong direction, ensuring precise linear displacement. It features a mounting flange with four un-tapped holes for M3 screws, and it's intended to be used with Tr8x8(P2) leadscrews. These leadscrews are 8 mm-diameter rods with four independent trapezoidal threads spaced 2 mm apart. One full revolution of the rod results in an 8.0 mm linear displacement of the traveling nut.
The XYZ-Double Rail Gantry system is equipped with two linear actuators on the X-axis, a single linear actuator on the Y-axis, and one actuator on the Z-axis for movement. The length of the actuators is 1000mm, 500mm, and 250mm. Don't miss out on this great deal! Save 20% OFF on Kits.
